    Large Torque 200meter Waterwell Drilling Rig Machine For Rock Hard XYX-200

    Ask Lasest Price
    Brand Name : Beijun
    Model Number : XYX-200
    Certification : CE,ISO
    Price : USD 8000-15000 Set
    Payment Terms : L/C, T/T
    Supply Ability : 1000 Set/Sets per Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    Large Torque 200meter Waterwell Drilling Rig Machine For Rock Hard XYX-200

    XYX-200 Core Drilling Rigs 200m Water Well Drilling Rig Machine For Rock Hard


    Characteristics
    1. Power can be equipped by electrical motor or diesel engine, as per your project needs;
    2. Hoist adopts Frictional clutch mechanism, using powder metallurgy friction plate,with good performance and long service life; With rapid and convenient hydraulic movable base, reliable hydraulic position locking, greatly improve the working efficiency before drilled hole, such as adding and taking off the drill rods ;
    3. Hydraulic part: piston rod adopts stern sealing ring(sealing ring for shaft),hydro-cylinder piston adopts Glyd ring(sealing ring for hole), up to international advanced level, with good sealing performance and durability;
    4. Easy to be disassembled, installed and operation.
    5. With large rotary torque which are better than the other same level drilling machines. The rotaryunit has different rotating speed grades, which can meet the requirements in different layers and different drilling projects.


    Drilling depth200m
    Hole diameter300mm
    End hole diameter75mm
    Drill pipe diameter60mm
    Dip angle of hole90°~75°
    Rig weight (excluding power)1300kg
    Cone beltb950×4 b1700×3
    Active moving distance300mm
    Motive power22hp/16.2kw
    Vertical shaft
    Speed of vertical shaft64 128 287 557 r/min
    Vertical axis travel450mm
    Jenny
    Single rope lifting weight2400kg
    Single rope lift0.41 0.82 1.64m/s
    wire rope diameter13mm
    Wire rope capacity35m
    Block diameter260mm
    Gate width70mm
    Mud pump
    Pressure3mpa
    working pressure1.5mpa
    Water inlet diameter40mm
    Diameter of outflow tube30mm
    cone beltb1728mm
    hydraulic pump
    specificationscbt—f—314
    cone beltb1100× 1
