    25 Ton Articulated Dump Truck 6x4

    Ask Lasest Price
    Brand Name : Beijun
    Model Number : UQ-25
    Certification : CE,ISO
    Payment Terms : L/C, T/T
    Supply Ability : 1000 Set/Sets per Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    25 Ton Articulated Dump Truck 6x4

    Product Features of 25 Ton Mining Underground Dump Truck Tipper Truck


    Beijun underground tunnel dump truck is a specialized vehicle that offers a range of features designed to meet the unique demands and challenges of operating in underground environments. Its compact and efficient design allows it to operate seamlessly in narrow spaces, while its improved safety features ensure that it can operate safely in hazardous conditions.

    The powerful performance of the truck's engine, combined with its high bearing capacity, makes it capable of efficiently transporting heavy loads in the underground environment. Additionally, the truck's durability and sturdy construction ensure that it can withstand the harsh conditions of underground mining and construction operations.

    Overall, the Beijun underground tunnel dump truck is a reliable and efficient choice for businesses and organizations that require a practical and robust vehicle for their operations in underground spaces. Its advanced features, including its compact design, improved safety features, powerful performance, and high bearing capacity and durability, make it an ideal choice for a range of tasks in narrow underground spaces.


    Product parameters of 25 Ton Mining Underground 25 Ton Dump Truck Tipper Truck

    ModelUQ-25
    Engine ModelYuchai YC6L340-33
    Engine Power243KW
    Total Dimension7900x2420x2720mm
    Transmission ModelFASITE RT11509C
    Transmission Gear10 Forward Gear, 2Back Gear,Rear High Speed Controller
    Drive Mode6x4
    Front Axle ModelStyer Axle
    Rear Axle ModelStyer Axle
    Tire Model1100R20 Radial steel tire,
    Rear Double Tyre One Side,
    No.of Bottom Spring PlateFront 11 PCS, Rear 12 PCS
    Dimension of Bottom Spring PlateFront 90*16
    Rear 90*24
    Size of the Bucket:Length×width×height5000x2300x1200mm
    Type of BucketRight Angle Type
    Thickness of Bucket Steel Platebottom 10mm side 8mm
    Unloading TypeHydraulic Double Top Dump
    Steering TypeHydraulic power steering
    Braking TypeAir Brake
    CabinClosed Cabin with A/C
    Driving PositionLeft Hand Drive
    Cooling sytemStandard Water Cooling System
    Loading Capacity25 Tons

    25 Ton Articulated Dump Truck 6x425 Ton Articulated Dump Truck 6x425 Ton Articulated Dump Truck 6x4
