    20 Tons Small Articulated Dump Truck Articulated Rock Truck 218kN XTUT-20

    Ask Lasest Price
    Brand Name : Beijun
    Model Number : XTUT-20
    Certification : CE,ISO
    Payment Terms : L/C, T/T
    Supply Ability : 1000 Set/Sets per Month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    20 Tons Small Articulated Dump Truck Articulated Rock Truck 218kN XTUT-20

    20 Tons XTUT-20 Self Underground Mining Articulated Dumping Truck


    XTUT-20 is a compact underground mining dump truck with a carrying capacity of 20 tons. It is equipped with a central articulated swing device and can be applied to 3 × 3 meters underground mine gallery transportation. The new design of XTUT-20 not only improves production efficiency, but also improves safety, maintainability and operational comfort in underground transportation, mining and construction operations.


    The heavy-duty front and rear frames are specially designed to cope with the harsh underground environment. The excellent quality, reliability and durability meet the requirements of users, making transportation simpler, more efficient and more efficient.


    The forward, front and fully enclosed air-conditioned cab provides a very comfortable operating environment without affecting the operator's field of vision. XTUT-20 is very suitable for production and transportation of ramps or horizontal roadways in small and medium-sized mines and small tunnel projects.


    设备设计所依照标准

    Industry standard and regulation

    JB/T8436地下矿用轮胎式运矿车

    JB/T8436 China Underground dump truck standard

    GB21500地下矿用无轨轮胎式运矿车安全要求

    GB21500 safety requirements of Underground dump truck standard, China

    Power train动力系统

    柴油机

    Diesel engine

    VOLVO TAD853VE

    额定功率

    Rated power

    235 kW @2200rpm

    额定扭矩

    MAX torque

    1310Nm @ 1450rpm

    气缸数

    Number of cylinders

    直列 6缸

    Straight 6 cylinder

    排气量

    Displacement

    7.7 L

    冷却系统

    Cooling system

    水冷发动机

    Liquid cooled

    燃烧原理

    Combustion principle

    4冲程直喷发动机,增压中冷

    4-stroke direct injection engine, turbocharge and inter-cooler

    进气空滤过滤

    Intake system

    干式空气过滤,预滤+两级过滤

    dry-type air filter,pre-filtration +two-stage filtration

    控制系统

    Control system

    燃油电子控制喷射系统

    Fuel electronic control injection system

    电气系统

    Starting system

    24 V

    排放标准

    Emission standard

    Euro stage Ⅲ

    排气系统

    Exhaust system

    DOC+POC+消音器

    DOC+POC+silencer

    平均油耗,

    负载50%时

    Average fuel consumption,

    When loading at 50%

    23.5L/h

    燃油箱容积

    Fuel tank capacity

    370L
